6 meter Institutionel aluminiummast

vertical_align_bottom Instruktioner til montering vertical_align_bottom Datablad
vertical_align_bottom Skabelon vertical_align_bottom Instruktioner Design
  1. Vælg antal
  2. Priser (Gratis transport)

    Priserne er udelukkende tilgængelige for registrerede distributører

6 meter Institutionel aluminiummast

Vores institutionsstang er den stærkeste og højeste på vores lager. Den anbefales til udendørs brug på grund af dens modstandsdygtighed over for vejrforhold. Den er lavet af aluminium, og takket være dens basissystem er det muligt at skille den ad, folde den ned og samle den op for at skifte flag eller beskytte den mod stærk vind.

Indhold

Institutionsmasten har alt, hvad der er nødvendigt til installation og montering, herunder:

  • Anodiseret aluminiumsmast.
  • Trekantet fod i galvaniseret stål.
  • Inkluderet tilbehør (klampe, faldline og pinnacle)
  • Institutionsflag (medfølger ikke)

Mastens dimension

Masten har enhøjde på 6 meter og en diameter på 6,5 cm. Den består af to aluminiumsprofiler, der er sat sammen på en vandtæt måde.

Feature

Description

Composition

Anodized aluminum with performance parameters PN-EN 755-2, 6063T66 with corrosion protection Al/An 15 µm class 3.

Dimensions

Pole (2 sections):


Height Diameter Thickness
Full pole 6000 mm - -
Lower section 3300 mm 65 mm 2.5 mm
Upper section 3000 mm 50 mm 2 mm

Triangular base:

Triangular iron base with 3 ground anchor bolts, each 50 cm long and 1.5 cm in diameter. It includes a hinge that allows the pole to be tilted, making it easier to install the flag.

Included accessories

This pole for horizontal flags comes with all the necessary parts for assembly included in the price. These include the following accessories:



- Rope. White nylon. Weather-resistant. Length between 16 and 20 meters.

- Halyard system. Mechanism that allows the flag to be raised by pulling the rope. Already installed in the upper section, it has a threaded top where the finial is screwed in.

- Finial. Piece that finishes the top of the pole and adds aesthetics. It has an onion shape and is made of silver-gray plastic. Its size is 14 cm in height and 14 cm in diameter at the center.

- Cleat. Already installed, made of durable white plastic, ideal for securing the hoisting rope. Its design allows the rope to be wrapped safely and neatly, preventing tangling



Weight

20 kg, approximately.

Colors

The main elements are silver-gray or metallic in color.



Accessory parts have a white plastic finish.

Materials

Pole made of anodized aluminum with a thickness of 2.5 mm.



It is made up of 2 anodized aluminum sections joined in a

airtight way. The cleat is located 1.5 meters from the base of the pole.



The base is oven-galvanized steel.

Color

Metallic silver gray.

Uses/Others
  • Recommended for outdoor use.

  • Assembly difficulty is medium. Requires approximately 15–20 minutes.


  • Concrete setting and installation are not included.

Accessories not included

Recommended flags (not included):



- Institutional flags.

- Horizontal flags.
