6-metrinen institutionaalinen alumiinimasto

vertical_align_bottom Kokoonpano-ohjeet vertical_align_bottom Tietolehti
vertical_align_bottom PDF-malli vertical_align_bottom Ohjeet
  1. Määrä
  2. Hinnat (ilmainen toimitus)

    Hinnat ovat saatavilla ainoastaan rekisteröidyille jakelijoille

6-metrinen institutionaalinen alumiinimasto

Meidän institutionaalinen masto on varastomme vahvin ja korkein. Se soveltuu erityisesti ulkokäyttöön, sillä se kestää hyvin sääolosuhteita. Masto on valmistettu alumiinista ja sen jalustajärjestelmän ansiosta se voidaan purkaa, kallistaa ja laskea alas lipun vaihtamista tai suojaamista varten kovilta tuulilta.

Sisältö

Institutionaalinen masto sisältää kaiken tarvittavan asennukseen ja kokoamiseen:

  • Anodisoitu alumiinimasto
  • Galvanoidusta teräksestä valmistettu kolmikulmainen jalusta
  • Mukana toimitettavat lisävarusteet (kiinnitysteline, pyörivä nostoköysijärjestelmä ja huippukoriste)
  • Institutionaalinen lippu (ei sisälly toimitukseen)

Maston mitat

Maston korkeus on 6 metriä ja halkaisija 6,5 cm. Se koostuu kahdesta alumiiniputkesta, jotka on liitetty tiiviisti toisiinsa.

Feature

Description

Composition

Anodized aluminum with performance parameters PN-EN 755-2, 6063T66 with corrosion protection Al/An 15 µm class 3.

Dimensions

Pole (2 sections):


Height Diameter Thickness
Full pole 6000 mm - -
Lower section 3300 mm 65 mm 2.5 mm
Upper section 3000 mm 50 mm 2 mm

Triangular base:

Triangular iron base with 3 ground anchor bolts, each 50 cm long and 1.5 cm in diameter. It includes a hinge that allows the pole to be tilted, making it easier to install the flag.

Included accessories

This pole for horizontal flags comes with all the necessary parts for assembly included in the price. These include the following accessories:



- Rope. White nylon. Weather-resistant. Length between 16 and 20 meters.

- Halyard system. Mechanism that allows the flag to be raised by pulling the rope. Already installed in the upper section, it has a threaded top where the finial is screwed in.

- Finial. Piece that finishes the top of the pole and adds aesthetics. It has an onion shape and is made of silver-gray plastic. Its size is 14 cm in height and 14 cm in diameter at the center.

- Cleat. Already installed, made of durable white plastic, ideal for securing the hoisting rope. Its design allows the rope to be wrapped safely and neatly, preventing tangling



Weight

20 kg, approximately.

Colors

The main elements are silver-gray or metallic in color.



Accessory parts have a white plastic finish.

Materials

Pole made of anodized aluminum with a thickness of 2.5 mm.



It is made up of 2 anodized aluminum sections joined in a

airtight way. The cleat is located 1.5 meters from the base of the pole.



The base is oven-galvanized steel.

Color

Metallic silver gray.

Uses/Others
  • Recommended for outdoor use.

  • Assembly difficulty is medium. Requires approximately 15–20 minutes.


  • Concrete setting and installation are not included.

Accessories not included

Recommended flags (not included):



- Institutional flags.

- Horizontal flags.
